Description
Detailed Technical Specifications
Structural Features:
-
Frame made of cold-rolled steel, thickness 1.2–1.5 mm
-
Powder polymer coating RAL 7035 (light gray) or RAL 9003 (white)
-
Bolted connections ensure maximum structural strength
-
Height extension possible with additional sections
-
Stable supports with adjustable feet to compensate for uneven floors
Shelves and Load Capacity:
-
Metal shelf thickness: 0.8–1.0 mm with stiffening ribs
-
Evenly distributed load: up to 100 kg per shelf
-
Point load: up to 30 kg per linear meter
-
Total load capacity: up to 400 kg
-
Shelf height adjustment pitch: 25 mm
Standard Dimensions and Modifications:
-
Height: 1500 / 1800 / 2000 / 2200 mm
-
Width: 800 / 950 / 1200 mm
-
Depth: 300 / 400 / 500 / 600 mm
-
Shelf thickness: 18–25 mm (for chipboard versions)
Additional Options and Accessories:
-
Perforated shelves for improved ventilation
-
Side and back panels for enclosed storage
-
Pull-out drawers and containers
-
Label holders and price tags
-
Shelf dividers
-
Swivel casters with brakes for mobile versions
-
LED shelf lighting
-
Locks for product protection
Application Areas and Specifications:
Retail:
-
Grocery stores: canned goods, grains, household chemicals
-
Non-food products: stationery, tools, auto parts
-
Pharmacies: medicines, hygiene products
-
Bookstores: books, magazines
-
Clothing stores: shoes, boxed accessories
Warehouse and Logistics:
-
Order picking
-
Spare parts storage
-
Document archiving
-
Inventory management
-
Reserve storage
Offices and Institutions:
-
Office supplies storage
-
Archive documents and folders
-
Libraries and reading rooms
-
Medical rooms: instruments, medications
-
Educational institutions: textbooks, manuals
Manufacturing:
-
Component storage
-
Tool rooms
-
Laboratory equipment
-
Product samples
Advantages and Operating Features:
Economic Benefits:
-
Low cost with high functionality
-
Fast return on investment due to efficient space usage
-
Modular expansion of storage systems
-
Minimal maintenance costs
Ergonomic Features:
-
Optimal shelf height for easy access
-
FIFO (first in – first out) organization
-
Visual stock control
-
Convenient inventory checks
Safety and Reliability:
-
Resistance to mechanical damage
-
No sharp edges (rounded corners)
-
Corrosion resistance due to high-quality coating
-
Wall mounting option for additional stability
Environmental Friendliness:
-
Use of safe materials
-
Fully recyclable after service life
-
Long service life (up to 15–20 years)
Assembly and Adjustment:
Preparation:
-
Check completeness (drawings, specifications)
-
Prepare tools (wrenches, level, measuring tape)
-
Clean and prepare installation area
Assembly Process:
-
Frame assembly (uprights, crossbars)
-
Shelf installation at required height
-
Foot adjustment for stability
-
Strength check of all connections
-
Load testing
Assembly Time:
-
1 person: 30–45 minutes
-
2 persons: 15–25 minutes
Maintenance and Care:
-
Weekly cleaning and wiping
-
Monthly inspection of fasteners
-
Periodic level check
-
Bolt tightening if required
Warranty and Service:
-
Warranty period: 2–3 years
-
Replacement of individual components
-
Service and modernization options
-
Consultations on optimal use
